2NO+1NC Three Element Switch

Name: 2NO+1NC Three Element Switch
Brand: NAVAGO ELECTRONICS & ELECTRICALS
Price: 325 INR
Availability: InStock

Price 325 INR/ Number

Get a Price/Quote

2NO+1NC Three Element Switch Specification

Finish Type
Matte/Glossy

Temperature Range
-25C to +70C

Mechanical Life
1,000,000 operations

Rated Voltage
600V AC

Automation Grade
Manual

Response Time
20ms

Number of Module
Single

Circuit Type
2NO+1NC

Max. Current
10A

Protection Level
IP65

Product Type
2NO+1NC Three Element Switch

Material
Engineering plastics and metal alloy

Insulation Resistance
100 M (at 500V DC)

Contact Resistance
50 m

Max. Voltage
600V AC

Operating Temperature
-25C to +70C

Stoke
22 mm

Size
Appropriate for 22.5mm panel cutout

Color
Black housing (button color may vary)

Weight
Approx. 80g

Mounting Type
Panel mount

Current Rating
10A

No Of Poles
3

Panel Thickness Mounting
0.8 mm 6 mm

Operation Force
3.5N

Standards Compliance
IEC 60947-5-1

Dielectric Strength
2,500V AC, 1 min

Contact Material
Silver Alloy

Ambient Humidity
85% RH

Terminal Type
Screw type

Switch Function
Momentary

2NO+1NC Three Element Switch Trade Information

Minimum Order Quantity
10 Number

Supply Ability
1000 Per Month

Delivery Time
3 Week

About 2NO+1NC Three Element Switch

Purchase the supreme 2NO+1NC Three Element Switch for your electrical needs and ensure ultimate performance combined with excellent reliability. This panel mount switch, compliant with IEC 60947-5-1 standards, operates with a maximum current of 10A at 600V AC and features a momentary switch function with silver alloy contacts for enhanced conductivity. Order now for the best price and benefit from outstanding durability, with a mechanical life of over 1,000,000 operations. Its IP65 rating guarantees protection, suitable for demanding environments. Ideal for exporters, manufacturers, and suppliers across India.

Versatile Applications and Noteworthy Features

The 2NO+1NC Three Element Switch is designed for control panels, machinery, and automation systems requiring supreme precision and reliability. Its robust engineering plastic and metal alloy construction, along with a protection level of IP65, allow operation in industrial environments with varying temperatures and humidity. Application media include electrical and electronic circuits, and its compact size fits standard 22.5mm panel cutouts, making it perfect for a wide range of installations and retrofitting projects.

Sample Policy, Main Export Markets, and Payment Details

We offer sample units at competitive rates, ensuring that clients can evaluate product quality before placing bulk orders. Handover of the samples is prompt, and freight charges are typically borne by the customer. Our main export markets include Asia, the Middle East, Africa, and Europe. Payment terms are flexible, accommodating advance payment, letter of credit, or net terms as per the agreement for seamless business transactions.

FAQ's of 2NO+1NC Three Element Switch:

Q: How do I install the 2NO+1NC Three Element Switch on a control panel?

A: Installation is straightforward-this switch fits into a standard 22.5mm panel cutout. Secure it using the screw-type terminals and ensure a proper fit between 0.8 mm to 6 mm panel thickness.

Q: What are the main benefits of using this supreme three element switch model?

A: You gain robust performance, excellent mechanical life (over 1,000,000 operations), high electrical insulation, and IP65-level protection, making it ideal for demanding industrial applications.

Q: Where is this switch most commonly used?

A: It is widely applied in industrial control panels, automation systems, machinery, and electrical equipment requiring reliable switching and safety.

Q: What is the process for ordering and receiving a sample?

A: Simply request a sample unit through our sales team; rates and freight details will be provided, and samples are handed over after payment and agreement of shipping terms.

Q: What payment terms are available for bulk export orders?

A: We offer customizable payment terms, including advance payment, letter of credit, or net terms, depending on the export agreement and client preferences.

Q: How does the dielectric and insulation strength benefit switch usage?

A: High dielectric strength (2,500V AC for one minute) and insulation resistance (100 M at 500V DC) ensure the switch's safety and stable operation in high-voltage applications.
